RSHDS Heavy Duty High Pressure Cartridge
Description
Overview
Features & benefits
- Fits standard big bore pumps
- Heavy duty construction
- Can replace double seals in many applications
- Flush, Quench and Drain standard
- Guided Quench
- Large radial clearances to allow for shaft deflection and/or eccentric installations
- Floating carbon bushing
- Excellent in crystallizing liquid
- Large cross section dynamic “O” ring
- Shrunk in stationary face
- Non-clogging design
Operating Limits
- Pressure : Up to 365 PSI / 25 Bar
- Temperature : From -40°F to 535°F, 40°C to 280°C
Standard Materials Of Construction
- Faces : Carbon / Silicon Carbide, Tungsten Carbide/ Silicon Carbide
- Elastomers : Buna, Viton*, PTFE, Neoprene, EPR, Kalrez*, FEP, AFLAS*
- Metallurgy : 316 SS, Alloy 20, Hast B+C*
