Features & benefits

• Incorporates circulation, Vent & Drain gland for quenching & Safety
• Throttle bushing standard
• One of the industry’s most aggressively priced stationary cartridges
• Easy cartridge installation
• Stationary multiple spring design with circulation vent & drain connections
• Springs isolated from product
• Rugged face design
• Identical seal face shapes make repairs easy & economical
• Hydraulically balanced design
• Handles pressure reversals & vacuum
• Big Bore gland alternatives
• Interchangeable parts with D2 dual cartridges
• User friendly setting clips
• Confined gland gaskets

Operating Limits

• Pressure : Up to 365 PSI / 25 Bar
• Temperature : From -40°F to 535°F, 40°C to 280°C
